<2. Specifications> 2-4
IM 11M10B01-01E
Response time
: 90% response
: Within 10 sec (0-1% or more)
: Within 30 sec (less than 0-1%)
Drift
: ±2% FS / week
2.3 Model and Suffix Codes
Model Suffix Code Description
Option
Code
OX400 Low Concentration Zirconia Oxygen Analyzer
Power supply -5 100-120 V AC
(Note 1) -3 200-240 V AC
Sampling method -P Built-in pump
-A With aspirator
-N No suction device
Line connection R Rc 1/4
T 1/4 NPT
User’s manual -J Japanese
-E English
Power cable (Note 1) -D UL/CSA cable (2 m)
-F VDE cable (2.5 m)
-H GB cable (2.5 m)
-Q BS cable (2 m)
-R SAA cable (2.5 m)
Option Mounting hardware /P Panel mount
Multi selector function /MS Multi selector function
Filter /A Activated carbon filter (Note 2)
(Note 1) Power cable of two-pole with earthing plug is attached.
Suffix code “-D” of power cable can not be specified when “-3” of power supply is specified.
Power cable of “-D” can be used in Japan, because another cable doesn’t conform to PSE marking.
(Note 2) When “R” of line connection is specified, K9643KH filter (Rc1/4) is attached,
when “T” of line connection is specified, K9643KJ filter (1/4NPT) is attached.
[Style: S2]
2.4 Standard Accessories
Check the standard and optional accessories when you receive the product.
Accessories
Item
Part no. and rating
Qt’y
Fuse A1113EF:
Time-lag T3.15 conformed to IEC60127
1
User’s manual IM 11M10B01-01E (English), -01 (Japanese) 1
Aspirator kit K9643KA (Rc1/4), K9643KB (1/4NPT) Optional
Panel mount kit K9643KC Optional
Activated carbon filter K9643KH (Rc1/4), K9643KJ (1/4NPT) Optional
