<5. Modbus Communication>
5-19
IM 01C25R05-01EN
Table 74
Ext SW
Code
Discription
0
Disabled
1
Enabled
Table 75
H/L Swap
Code
Discription
0
Normal
1
Reverse
Table 76
Low cut mode
Code
Discription
0
OFF
1
ON
Table 80
Disp Out 1
Code
Discription
0
Pres
1
SP
2
ET
3
Pres % Range
4
SP % Range
5
ET % Range
6
Engr Disp
7
Disp User Value 1
8
Disp User Value 2
9
Disp User Value 3
10
Disp User Value 4
11
Disp User Value 5
12
Disp User Value 6
13
Disp User Value 7
14
Disp User Value 8
15
Disp User Value 9
16
Disp User Value 10
17
Disp User Value 11
18
Disp User Value 12
19
Disp User Value 13
20
Disp User Value 14
21
Disp User Value 15
22
Disp User Value 16
Table 81
Disp Out 2 to 16
Code
Discription
0
Pres
1
SP
2
ET
3
Pres % Range
4
SP % Range
5
ET % Range
6
Engr Disp
7
Disp User Value 1
8
Disp User Value 2
9
Disp User Value 3
10
Disp User Value 4
11
Disp User Value 5
12
Disp User Value 6
13
Disp User Value 7
14
Disp User Value 8
15
Disp User Value 9
16
Disp User Value 10
17
Disp User Value 11
18
Disp User Value 12
19
Disp User Value 13
20
Disp User Value 14
21
Disp User Value 15
22
Disp User Value 16
250
Not used
Table 82
Disp % Reso
Code
Discription
0
Normal
1
High Resolution
Table 83
Bar Indicator
Code
Discription
0
Off
1
On
Table 84
Pres disp point
Code
Discription
0
Integer
1
Down to 1 place of decimals
2
Down to 2 places of decimals
3
Down to 3 places of decimals
4
Down to 4 places of decimals
