Page 37
<5. Modbus Communication>
5-6
IM 01C25R05-01EN
5.7.2 Address Map (Detail Information)
Address Label used in
DTM
Address Type Access Type
Char/
Date
Read/
Write Enum list
Default
Value
*1
Unit
Valid
Range
IM
Chapter
1001
Restart
Coil
SINGLE BIT
-
W
Table 1
0
-
0x0000,
0xFF00
1002
Squawk
Coil
SINGLE BIT
-
W
Table 1
0
-
0x0000,
0xFF00
3.4.8
1003
Error log Clear
Coil
SINGLE BIT
-
W
Table 1
0
-
0x0000,
0xFF00
1004
Auto Atm. Pres
Coil
SINGLE BIT
-
W
Table 1
0
-
0x0000,
0xFF00
1005
Reset cfg chng
count
Coil
SINGLE BIT
-
W
Table 1
0
-
0x0000,
0xFF00
4.1.3
1001-
1008
Status group 1
Discrete Input SINGLE
BIT×8
-
R
Table 6
-
-
-
4.1.1
1009-
1016
Status group 2
Discrete Input SINGLE
BIT×8
-
R
Table 7
-
-
-
4.1.1
1017-
1024
Status group 3
Discrete Input SINGLE
BIT×8
-
R
Table 8
-
-
-
4.1.1
1025-
1032
Status group 4
Discrete Input SINGLE
BIT×8
-
R
Table 9
-
-
-
4.1.1
1033-
1040
Status group 5
Discrete Input SINGLE
BIT×8
-
R
Table 10
-
-
-
4.1.1
1041-
1048
Status group 6
Discrete Input SINGLE
BIT×8
-
R
Table 11
-
-
-
4.1.1
1049-
1056
Status group 7
Discrete Input SINGLE
BIT×8
-
R
Table 12
-
-
-
4.1.1
1057-
1064
Status group 8
Discrete Input SINGLE
BIT×8
-
R
Table 13
-
-
-
4.1.1
1065-
1072
Status group 9
Discrete Input SINGLE
BIT×8
-
R
Table 14
-
-
-
4.1.1
1073-
1080
Status group 10 Discrete Input SINGLE
BIT×8
-
R
Table 15
-
-
-
4.1.1
1081-
1088
Status group 11 Discrete Input SINGLE
BIT×8
-
R
Table 16
-
-
-
4.1.1
1001
Distributor
Input Register USIGN16
-
R
-
0x0037
-
-
1002
Device Type
Code
Input Register USIGN16
-
R
-
0x0054
-
-
1003
Fld dev rev
Input Register USIGN8
-
R
-
-
-
-
1004
Software rev
Input Register FLOAT
-
R
-
-
-
-
1006-
1013
Model
Input Register USIGN32×4
ASCII
R
-
-
-
-
1014
Write protect
Input Register USIGN8
-
R
Table 31
0x0000
-
-
3.4.6
1015
Software seal
Input Register USIGN8
-
R
Table 32
0x0001
-
-
1025
Cfg chng count Input Register USIGN8
-
R
-
-
-
-
4.1.3
1101
Pres
Input Register FLOAT
-
R
-
-
-
-
3.3.2
1103
SP
Input Register FLOAT
-
R
-
-
-
-
3.3.2
1105
ET
Input Register FLOAT
-
R
-
-
-
-
3.3.2
1107
Pres Data
Quality
Pres Limit
Status
SP Data Quality
SP Limit Status
Input Register USIGN16
-
R
Table 5
-
-
-
4.1.3
1108
ET Data Quality
ET Limit Status
Reserved
Input Register USIGN16
-
R
Table 5
-
-
-
4.1.3
1109
Status group 1
Status group 2
Input Register USIGN16
-
R
Table 6
Table 7
-
-
-
4.1.1
1110
Status group 3
Status group 4
Input Register USIGN16
-
R
Table 8
Table 9
-
-
-
4.1.1
1111
Status group 5
Status group 6
Input Register USIGN16
-
R
Table 10
Table 11
-
-
-
4.1.1
*1:
This value is factory default of M range measurement span without order specification.
*2:
Upper case character can be used. Lower-case is translated to upper case.
