<5. Modbus Communication>
5-5
IM 01C25R05-01EN
5.7.1 Address Map (Basic Information)
Address Label used in
DTM
Address Type Access Type Char/
Date
Read/
Write Enum list
Default
Value *1
Unit
Valid
Range
IM
Chapter
0003 Calibration Flag Coil SINGLE BIT - W Table 1 0 - 0x0000,
0xFF00
3.4.4
0031 Clear P trim Coil SINGLE BIT - W Table 1 0 - 0x0000,
0xFF00
3.4.4
0032 Clear SP trim Coil SINGLE BIT - W Table 1 0 - 0x0000,
0xFF00
3.4.4
0033 Clear ET trim Coil SINGLE BIT - W Table 1 0 - 0x0000,
0xFF00
3.4.4
0050-
0075
Status Bits Discrete Input SINGLE
BIT×26
- R Table 2 0 - - 4.1.1
0001 Distributor Input Register USIGN8 - R - 0x0037 - -
0002 Device Type Input Register USIGN8 - R - 0x0054 - -
0003 Device rev Input Register USIGN8 - R - - - -
0016 Slave Address Holding
Register
USIGN8 - W - 0x0001 - 1 to 247 3.2
0401 Pres Input Register FLOAT - R - - - - 3.3.2
0403 SP Input Register FLOAT - R - - - - 3.3.2
0405 ET Input Register FLOAT - R - - - - 3.3.2
0407-
0410
Status Bytes Input Register USIGN32×2 - R Table 2 - - - 4.1.1
0413 Pres USL Input Register FLOAT - R - 100.0 kPa -
0415 Pres LSL Input Register FLOAT - R - -100.0 kPa -
0417 Pres URV Holding
Register
FLOAT - W - 100.0 kPa -110 to
110
3.3.3
0419 Pres LRV Holding
Register
FLOAT - W - 0.0 kPa -110 to
110
3.3.3
0421 SP USL Input Register FLOAT - R - 25.0 MPa -
0423 SP LSL Input Register FLOAT - R - 0.0 MPa -
0425 SP URV Holding
Register
FLOAT - W - 16.0 MPa -2.5 to
27.5
3.3.3
0427 SP LRV Holding
Register
FLOAT - W - 0.0 MPa -2.5 to
27.5
3.3.3
0429 ET USL Input Register FLOAT - R - 850.0 °C -
0431 ET LSL Input Register FLOAT - R - -200.0 °C -
0433 ET URV Holding
Register
FLOAT - W - 850.0 °C -210 to
860
3.3.3
0435 ET LRV Holding
Register
FLOAT - W - -200.0 °C -210 to
860
3.3.3
0437 Pres trim Auto
Lower Pt
Holding
Register
FLOAT - W - - - With in
adjustable
range
3.4.4
0439 Pres trim Auto
Upper Pt
Holding
Register
FLOAT - W - - - With in
adjustable
range
3.4.4
0441 Pres Damp Holding
Register
FLOAT - W - 2.0 s 0 to 100 3.3.5
0443 SP trim Auto
Lower Pt
Holding
Register
FLOAT - W - - - With in
adjustable
range
3.4.4
0445 SP trim Auto
Upper Pt
Holding
Register
FLOAT - W - - - With in
adjustable
range
3.4.4
0447 SP Damp Holding
Register
FLOAT - W - 1.0 s 0 to 100 3.3.5
0449 ET trim Auto
Lower Pt
Holding
Register
FLOAT - W - - - With in
adjustable
range
3.4.4
0451 ET trim Auto
Upper Pt
Holding
Register
FLOAT - W - - - With in
adjustable
range
3.4.4
0453 ET Damp Holding
Register
FLOAT - W - 1.0 s 0 to 100 3.3.5
*1: This value is factory default of M range measurement span without order specification.
