<5. Modbus Communication>
5-7
IM 01C25R05-01EN
Address Label used in
DTM
Address Type Access Type
Char/
Date
Read/
Write Enum list
Default
Value *1
Unit
Valid
Range
IM
Chapter
1112 Status group 7
Status group 8
Input Register USIGN16 - R Table 12
Table 13
- - - 4.1.1
1113 Status group 9
Status group 10
Input Register USIGN16 - R Table 14
Table 15
- - - 4.1.1
1114 Status group 11
Reserved
Input Register USIGN16 - R Table 16 - - - 4.1.1
1121 Pres % Range Input Register FLOAT - R - - - - 3.3.2
1123 SP % Range Input Register FLOAT - R - - - - 3.3.2
1125 ET % Range Input Register FLOAT - R - - - - 3.3.2
1127 Pres % Range
Data Quality
Pres % Range
Limit Status
SP % Range
Data Quality
SP % Range
Limit Status
Input Register USIGN16 - R Table 5 - - - 4.1.3
1128 ET % Range
Data Quality
ET % Range
Limit Status
Reserved
Input Register USIGN16 - R Table 5 - - - 4.1.3
1129 Cap temp Input Register FLOAT - R - - - -
1131 Amp temp Input Register FLOAT - R - - - -
1133 Engr Disp Input Register FLOAT - R - - - -
1301-
1304
Log1(Latest) Input Register USIGN32×2 - R Table 20 - - -
1305-
1308
Log2 Input Register USIGN32×2 - R Table 20 - - -
1309-
1312
Log3 Input Register USIGN32×2 - R Table 20 - - -
1313-
1316
Log4(Oldest) Input Register USIGN32×2 - R Table 20 - - -
1001-
1004
Tag Holding
Register
USIGN32×2 ASCII *2 W - - - - 3.3.1
1005-
1012
Descriptor Holding
Register
USIGN32×4 ASCII *2 W - spaces - - 3.3.1
1013 Date Holding
Register
USIGN32 Date W - 0x00010164 - - 3.3.1
1015-
1030
Long tag Holding
Register
USIGN32×8 ASCII W - - - - 3.3.1
1031 User Defined
Number
Holding
Register
USIGN16 - W - 0x0000 - -
1032-
1047
Message Holding
Register
USIGN32×8 ASCII *2 W - spaces - - 3.3.1
1048-
1063
MS Code 1 Holding
Register
USIGN32×8 ASCII *2 W - - - -
1064-
1079
MS Code 2 Holding
Register
USIGN32×8 ASCII *2 W - - - -
1080-
1095
MS Code 3 Holding
Register
USIGN32×8 ASCII *2 W - - - -
1096-
1099
Enable wrt
10min
Holding
Register
USIGN32×2 ASCII *2 W - spaces - - 3.4.6
1100-
1103
New password Holding
Register
USIGN32×2 ASCII *2 W - spaces - - 3.4.6
1104-
1119
Option
Password
Holding
Register
USIGN32×8 ASCII W - spaces - -
1120 Style No. Holding
Register
FLOAT - R - - - -
1122 Mftr Date Holding
Register
USIGN32 Date R - - - -
1124-
1131
Serial No. Holding
Register
USIGN32×4 ASCII *2 R - - - -
*1: This value is factory default of M range measurement span without order specification.
*2: Upper case character can be used. Lower-case is translated to upper case.
