Address Label used in
DTM
Address Type Access Type
Char/
Date
Read/
Write Enum list
Default
Value
*1
Unit
Valid
Range
IM
Chapter
1461
ET LRV
Holding
Register
FLOAT
-
W
-
-200.0
°C
-210 to
860
3.3.3
1463
Pres USL
Holding
Register
FLOAT
-
R
-
100.0
kPa
-
1465
Pres LSL
Holding
Register
FLOAT
-
R
-
-100.0
kPa
-
1467
Pres Min span
Holding
Register
FLOAT
-
R
-
0.5
kPa
-
1469
SP USL
Holding
Register
FLOAT
-
R
-
25.0
MPa
-
1471
SP LSL
Holding
Register
FLOAT
-
R
-
0.0
MPa
-
1473
SP Min span
Holding
Register
FLOAT
-
R
-
1.0
MPa
-
1475
ET USL
Holding
Register
FLOAT
-
R
-
850.0
°C
-
1477
ET LSL
Holding
Register
FLOAT
-
R
-
-200.0
°C
-
1479
ET Min Span
Holding
Register
FLOAT
-
R
-
10.0
°C
-
1551
Pres Damp
Holding
Register
FLOAT
-
W
-
2.0
s
0 to 100
3.3.5
1553
SP Damp
Holding
Register
FLOAT
-
W
-
1.0
s
0 to 100
3.3.5
1555
ET Damp
Holding
Register
FLOAT
-
W
-
1.0
s
0 to 100
3.3.5
1601
Pres trim Auto
Upper Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
1603
Pres trim Auto
Lower Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
1605
Pres trim
Manual Upper
Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1607
Pres trim
Manual Lower
Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1609
SP trim Auto
Upper Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1611
SP trim Auto
Lower Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1613
SP trim Manual
Upper Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1615
SP trim Manual
Lower Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1617
ET trim Auto
Upper Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1619
ET trim Auto
Lower Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1621
ET trim Manual
Upper Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1623
ET trim Manual
Lower Pt
Holding
Register
FLOAT
-
W
-
-
-
With in
adjustable
range
3.4.4
1625
Trim Clear Code Holding
Register
USIGN8
-
W
Table 72
0x0000
-
0 to 5
3.4.4
*1:
This value is factory default of M range measurement span without order specification.
*2:
Upper case character can be used. Lower-case is translated to upper case.
