-2-
1 External Drawings and Dimensions
Unit mm:[in.]
The CA3-ISO232-01 and CA3-ISO485-01 are a CE marked, EMC compliant products.
These units conform to EN55011 Class A and EN61000-6-2 directives.
CE Marking
Please check that the following items are included in your package.
„ „ „ „ „ Isolation Unit
RS-232C Isolation Unit ....... CA3-ISO232-01
RS-485 Isolation Unit .......... CA3-ISO485-01
„ „ „ „ „ Installation Guide (this guide)
„ „ „ „ „ Attachment Screws (2)
Package Contents
110[4.33]
40[1.57]
27[1.06]
PLC
Display
toto AGPA
G
P
420[16.54] 48[1.89]
toto AGPA
G
P 31
[1.22]
B
A
RS -232C Is olation Unit RS-485 Is olation Unit
Com munication
M ethod
RS -232C RS-485
Interface D-S ub 9-pin s ock et D-Sub 9-pin plug
Com munication
M ethod RS -232C / RS -422
(Via DIP s witc h) RS-485 / RS -422
(V ia DIP switch)
Interface D-S ub 9-pin plug D-Sub 9-pin s oc ket
Input
(Display
Side)
Output
(PLC Side)
A
B
