Chapter 1 – Hardware Configuration
Maple Systems
1010-1016 Rev 00
www.maplesystems.com
DIP Switch Modes
SW1
SW2
SW3
SW4
Mode
ON
OFF
OFF
OFF
Touchscreen Calibration
OFF
ON
OFF
OFF
Reserved
OFF
OFF
ON
OFF
Boot loader mode
OFF
OFF
OFF
ON
Reserved
OFF
OFF
OFF
OFF
Normal Operation
Boot Loader Mode
This mode allows users to load a new Windows CE image file.
To load a new image file from an SD card:
1.
Turn off Open HMI.
2.
Load the image onto an SD card.
3.
Insert SD card into unit or SD card reader.
4.
Set DIP SW3 to ON.
5.
Reapply power to the OMI5000 Series Open HMI. Open HMI will boot in Boot Loader Mode.
6.
The image file will automatically load and Open HMI automatically reboots when the download
is complete. While loading the CPU LED will flash continuously. The download takes several
minutes to complete.
7.
Be sure to reset all DIP switches to OFF before turning on the Open HMI the next time, or it will
load in Boot Loader Mode.
Contact Maple Systems for Information on the operating system image files
