RPC-6010G Rackmount LCD Workstation
The following IEI backplanes, motherboards and power supply units are recommended for
the RPC-6010G rackmount workstation. For more information about these backplanes
please contact an IEI sales representative or visit the IEI website ( www.ieiworld.com ).
B.1 Recommended IEI Backplanes and Motherboards
The following table lists the recommended IEI backplanes and motherboards for the
RPC-6010G rackmount workstation.
PCIe
Model No. SBC Type PCI ISA
X1 X4 X16
PSU
Connector
PCI-13SD-RS-R30 PICMG 1.0 3 + 4 3 + 3 0 0 0 AT/ATX
PCI-14S2-RS-R30 PICMG 1.0 4 8 0 0 0 AT/ATX
PCI-14S3-RS-R30 PICMG 1.0 4 9 0 0 0 AT/ATX
PX-14S3-RS-R30 PICMG 1.0 12 2 0 0 0 AT/ATX
PX-14S5-RS-R30 PICMG 1.0 7 6 0 0 0 AT/ATX
BP-14S-RS-R30 ISA 0 14 0 0 0 AT
PXAGP-13S3-RS-R30 PIAGP 11 0 0 0 0 AT/ATX
PE-13SD PICMG 1.3 4 0 5 0 2 ATX
PXE-13S PICMG 1.3 8 0 3 0 1 ATX
PXE-13S2 PICMG 1.3 4 0 7 0 1 ATX
PXE-13S3 PICMG 1.3 3 0 0 8 1 ATX
Table B-1: Recommended IEI Backplanes and Motherboards
