2.1.4 Left Side Panel

The RPC-6010G rackmount workstation has the following left side panel items:

Cooling vents

Figure 2-6: RPC-6010G Left Side Panel

2.2 Physical Dimensions

The following sections describe the physical dimensions of the RPC-6010G.

2.2.1 General Physical Dimensions

General physical dimensions for the RPC-6010G are shown in Table 2-1.

Width

(mm)

Height

(mm)

Depth

(mm)

431 177 528

Table 2-1: General Physical Dimensions
