IEI Integration RPC-6010G - Manual (Page 68)

RPC-6010G Rackmount LCD Workstation
5.7.2 5.25” Disk Drive Replacement
To replace a 5.25” disk drive, please follow the instructions below.
NOTE:
These instructions are also applicable for replacement of a 3.5” disk drive
mounted in a 5.25” disk drive adapter bracket. Refer to Section 4.5.6.2 for
instructions on installing a 3.5” disk drive into a 5.25” drive bay slot.
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
Step 9:
Step 10:
Step 11:
Step 12:
Turn off and disconnect the workstation from all power sources.
Remove the workstation from the rack in which it is installed.
Open the top cover of the RPC-6010G rackmount workstation.
(See Section 4.5.1)
Remove the CPU card clamp. (See Section 4.5.2)
Remove the dual CPU card clamp and drive bay stabilizer bracket. (See
Section 4.5.3)
Disconnect all cabling from every hard drive.
Remove the drive bracket (see Section 4.5.4).
Remove the retention screws that secure the 5.25” disk drive to the drive
bracket and slide the drive out of the bracket.
Install the new 5.25” disk drive. (See Section 4.5.6.3)
Reinstall the drive bracket to the workstation. (See Section 4.5.7)
Reconnect all disk drive cabling.
Close the top cover of the workstation and reinstall the workstation into the
cabinet or rack in which it was previously installed. Refer to Section 4.6 for
complete mounting instructions. Step 0:
Page 58
