IEI Integration RPC-6010G - Manual (Page 48)

RPC-6010G Rackmount LCD Workstation
Step 2:
Step 3:
Step 4:
Step 5:
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
If necessary, remove the CPU card clamp. (See Section 4.5.2)
If necessary, remove the dual CPU card clamp and drive bay stabilizer bracket.
(See Section 4.5.3)
Slide the PCI/ISA expansion card into the reserved PCI/ISA socket on the
backplane.
To secure the PCI/ISA expansion card, reinsert the previously removed slot
cover retention screw. Step 0:
If necessary, reinstall the CPU card clamp.
If necessary, reinstall the dual CPU card clamp and drive bay stabilizer bracket.
4.5.11 Installing Short Cards
When installed, some cards may still fall short below the CPU card clamp. To better
secure the CPU card or expansion cards, use the short card clamps that came with the
workstation.
Locate the screw hole on the CPU card clamp closest to the target card.
Adjust the short card clamp in a vertical direction until the shock absorber part of
the clamp secures the expansion card.
Fasten a screw to secure the card clamp. Step 0:
Page 38
