ECN-680A-H61 Em b e d d e d S ys te m
P a g e 77
5.3.8 H/W Mo n ito r
The H/W Monitor menu (BIOS Menu 12) shows the hardware health status.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+46 C
System1 Temperature :+34 C
System2 Temperature :+34 C
CPU Fan Speed :3500 RPM
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: Hardware Health Configuration
 PC He alth Statu s
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System1 Temperature (CN5)
o System2 Temperature (CN6)
 Fan Speeds:
o CPU Fan Speed
5.3.9 S e ria l P o rt Co n s o le Re d ire c tio n
The Serial Port Console Redirection menu (
378H
BIOS Menu 13) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
