ECN-680A-H61 Em b e d d e d S ys te m
P a g e 7
NOTE:
If the CPU temperature alert LED shows in red, the user must lower the
environments temperature or close some running applications to cool
down the CPU.
1.6 Re a r P a n e l
The rear panel of the ECN-680A-H61 has the following features (Figure 1-4):
 1 x AT/ATX Switch
 1 x DVI-D port
 1 x DVI-I port
 1 x HDMI port
 1 x 9 V ~ 36 V power jack
 1 x Reset button
 2 x RJ-45 LAN connectors
 2 x RS-232 (DB-9 connector)
 1 x RS-232 (RJ-45 connector)
 1 x RS-422/485 (DB-9 connector)
 1 x Temperature sensor
 4 x USB 2.0 connectors
