ECN-680A-H61 Em b e d d e d S ys te m

P a g e 21

Figure 3-9: Close the CPU Socket

S te p 12:

Install the fan module in the same position it was before and tighten the eight fan

bracket retention screws. See Section 3.3.

S te p 13:

Connect the fan connector (CPU_FAN1). See Section 3.3.

S te p 14:

Replace the cover and secure it using five previously removed retention screws.

See Section 3.3.

3.5 Ha rd Dis k Drive (HDD) In s ta lla tio n

To install the hard drive, please follow the steps below:

S te p 1:

Remove four (4) retention screws from the HDD cover, two from the bottom

panel and two from the right side, as shown in
