ECN-680A-H61 Em b e d d e d S ys te m
P a g e 86
 Maximum D
EFAULT
 IGD - Bo o t Typ e [VBIOS Defau lt]
Use the IGD - Boot Type option to select the display device used by the system when it
boots. For dual display support, select “Auto.” Configuration options are listed below.
 VBIOS Default D EFAULT
 DVI-I
 DVI-D
 HDMI
5.6 Bo o t
Use the Boot menu (
383H
BIOS Menu 20) to configure system boot options.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
Bootup NumLock State [On]
Quiet Boot [Enabled]
Option ROM Messages [Force BIOS]
Launch PXE Boot [Disabled]
UEFI Boot [Disabled]
Boot Option Priorities
Boot Option #1 [SATA PM：SAMSUNG…]
Hard Drive BBS Prioties
Select the keyboard
NumLock state
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 20: Boot
 Bo o tu p Nu m Lo ck State [On ]
Use the Bootup NumLock State BIOS option to specify if the number lock setting must
be modified during boot up.
