NOVA-PV-D5251/D4251 5.25" SBC
Page 66
Figure 4-2: CompactFlash® Card Installation
4.5 Jumper Settings
NOTE:
A jumper is a metal bridge used to close an
electrical circuit. It consists of two or three metal
pins and a small metal clip (often protected by a
plastic cover) that slides over the pins to connect
them. To CLOSE/SHORT a jumper means
connecting the pins of the jumper with the plastic
clip and to OPEN a jumper means removing the
plastic clip from a jumper.
Figure 4-3: Jumper Locations
Before the NOVA-PV-D5251/D4251 is installed in the system, the jumpers must be set in
accordance with the desired configuration. The jumpers on the NOVA-PV-D5251/D4251
are listed in
7
Table 4-1.
