NOVA-PV-D5251/D4251 5.25" SBC

Page 65

Step 4:

Removing a SO-DIMM. To remove a SO-DIMM, push both handles outward.

The memory module is ejected by a mechanism in the socket.

Step 0:

4.4 CompactFlash® Installation

NOTE:

Both CompactFlash® Type I and Type II cards are supported.

To install the CompactFlash® card, please follow the steps below.

Step 1:

Locate the CF card slot.

Step 2:

Align the CF card. Align the CompactFlash® card. The label side should be

facing away from the board. The grooves on the CompactFlash® slot ensure

that the card cannot be inserted the wrong way.

Step 3:

Insert the CF card. Push until the CompactFlash® card is firmly seated in the

slot. See Figure 4-2.
