NOVA-PV-D5251/D4251 5.25" SBC
Page 116
5.4.3 Intel IGD SWSCI OpRegion
Use the Intel IGD SWSCI OpRegion menu to configure the video device connected to the
system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT Mode Select
[DVMT Mode]
DVMT/FIXED Memory [Maximum]
IGD – Boot Type [VBIOS Default]
LCD Panel Type [Select by Panel ID]
Panel ID Resolution 800x600 18bit
Select the DVMT/FIXED
Mode Memory size used by
Internal Graphics
Device.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 16: Intel IGD SWSCI OpRegion
Î DVMT Mode Select [DVMT Mode]
Use the DVMT Mode Select option to select the Intel Dynamic Video Memory Technology
(DVMT) operating mode.
Î
Fixed Mode A fixed portion of graphics memory is reserved as
graphics memory.
Î
DVMT Mode D EFAULT Graphics memory is dynamically allocated according to
the system and graphics needs.
Î DVMT/FIXED Memory [Maximum]
Use the DVMT/FIXED Memory option to specify the maximum amount of memory that
can be allocated as graphics memory. Configuration options are listed below.
ƒ 128 MB
ƒ 256 MB
