5.3.7 H/W Monitor
The H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan speeds
and system voltages.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
PC Health Status
CPU Temperature
:+65 C
SYS Temperature
:+39 C
CPU FAN Speed
:N/A
SYS FAN Speed
:N/A
VCC3V
:+3.312 V
V_core :+1.160
V
V1.05S
:+1.048 V
Vcc3S
:+3.332 V
Vcc5V
:+5.045 V
VSB3V
:+3.312 V
VBAT
:+3.248
V
CPU Smart Fan Control
[Auto Mode]
Temperature Bound 1
60
Temperature Bound 2
50
Temperature Bound 3
40
Temperature Bound 4
30
SYS Smart Fan Control
[Auto Mode]
Temperature Bound 1
60
Temperature Bound 2
50
Temperature Bound 3
40
Temperature Bound 4
30
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General
Help
F2 Previous
Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
Î CPU Smart Fan Control [Auto Mode]
Use the CPU Smart Fan Control option to configure the CPU fan.
