NANO-QM57A EPIC SBC
Page 69
5.3.6 H/W Monitor
The H/W Monitor menu (BIOS Menu 9) shows the operating temperature, fan speeds and
system voltages.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU Temperature
:+53 C
SYS Temperature :+29 C
CPU FAN Speed
:4702 RPM
SYS FAN Speed :N/A
VIN0(VCC3C) :+3.296
V
VIN1(VCORE) :+1.056 V
VIN2(+1.5V) :+1.512 V
VSB3V :+3.312 V
VBAT :+3.184 V
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 9: Hardware Health Configuration
Î Smart Fan Mode Configuration [Auto Fan by RPM]
Use the Smart Fan Mode Configuration option to configure the CPU fan.
