NANO-QM57A EPIC SBC
Page 22
Pin Description Pin Description
13 CLK+ 14 LAD1
15 GND 16 LAD0
17 PCIRST# 18 GND
19 LPC 20 VCC3
21 GND 22 PCIRST#
23 PERN2 24 3VDual
25 PERP2 26 GND
27 GND 28 1.5 V
29 GND 30 SMBCLK
31 PETN2 32 SMBDATA
33 PETP2 34 GND
35 GND 36 USBD-
37 GND 38 USBD+
39 VCC3 40 GND
41 VCC3 42 N/C
43 GND 44 RF_LINK#
45 SATATXP2/CL_CLK 46 BLUELED#
47 SATATXN2/CL_DATA 48 1.5 V
49 SATARXN2/CL_RST# 50 GND
51 SATARXP2 52 VCC3
Table 3-10: PCIe Mini Card Slot Pinouts
3.2.9 12V Power Connector
CN Label: PWR2
CN Type: 4-pin Molex power connector (1x4)
CN Location: See Figure 3-10
CN Pinouts: See Table 3-11
The connector supports the 12V power supply.
