NANO-9452 EPIC Motherboard
Page 81
NOTE:
IEI has a wide range of backplanes available. Please contact your
NANO-9452 vendor, reseller or an IEI sales representative at
[email protected] or visit the IEI website ( http://www.ieiworld.com.tw )
to find out more about the available chassis.
5.5.2 Motherboard Installation
To install the NANO-9452 motherboard into the chassis please refer to the reference
material that came with the chassis.
5.6 Internal Peripheral Device Connections
5.6.1 Peripheral Device Cables
The cables listed in Table 5-7 are shipped with the NANO-9452.
Quantity Type
1 IDE Cable
1 KB/MS cable
2 SATA drive cables
1 SATA drive power cable
Table 5-7: IEI Provided Cables
Optional cables are listed below:
USB cable
TV out cable
RS-232/422/485 cable
LPT cable
RS-232 cable
7.1 channel audio kit
