NANO-9452 EPIC Motherboard
Page 201
Sound Effect
Karaoke Mode
Equalizer
Speaker Configuration
Speaker Test
S/PDIF-In
S/PDIF-Out
Connector Sensing
HRTF Demo
Microphone Effect
General
NOTE:
Not all Realtek Sound Effect Managers have all the above listed
options. The Sound Effect Manager loaded onto the system may only
have some of the options listed above.
Below is a brief description of the available configuration options in the Sound Effects
Manager.
Sound Effect - Select a sound effect from the 23 listed options in the drop
down menu. Selected sound effect properties can be edited. Click EDIT to
edit the sound effect.
Karaoke Mode - Karaoke Mode is accessed in the Sound Effect tab. The
Voice Cancellation disables the vocal part of the music being played. The
Key adjustment up or down arrow icons enable users to define a key that fits
a certain vocal range.
Equalizer Selection - Preset equalizer settings enable easy audio range
settings. Ten frequency bands can be configured.
Speaker Configuration - Multi-channel speaker settings are configured in
this menu. Configurable options include:
o Headphone
o Channel mode for stereo speaker output
o Channel mode for 4 speaker output
