NANO-9452 EPIC Motherboard

Page 37

Figure 4-7: CF Card Socket Location

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1 GROUND 26

VCC-IN

CHECK1

2

DATA 3

27

DATA 11

3

DATA 4

28

DATA 12

4

DATA 5

29

DATA 13

5

DATA 6

30

DATA 14

6

DATA 7

31

DATA 15

7 HDC_CS0#

32

HDC_CS1

8 N/C

33

N/C

9 GROUND 34

IOR#

10 N/C

35 IOW#

11 N/C

36 VCC_COM

12 N/C

37 IRQ15

13 VCC_COM 38 VCC_COM

14 N/C

39 CSEL
