NANO-9452 EPIC Motherboard
Page 32
Connector Type Label
Inverter power connector 5-pin header INVERTER1
Keyboard and mouse connector 6-pin wafer KB1
LVDS connector 30-pin crimp LVDS1
Parallel port connector 26-pin header LPT1
PCI-104 slot 104-pin slot PC104_PLUS1
PCIe Mini Card slot 52-pin slot CN4
Serial ATA (SATA) connector 7-pin SATA connector SATA1
Serial ATA (SATA) connector 7-pin SATA connector SATA2
Serial port connector (COM 2) 14-pin header COM2
Serial port connector (COM 3) 10-pin header COM3
Serial port connector (COM 4) 10-pin header COM4
TV out connector 6-pin header TV1
USB connector 8-pin header USB01
USB connector 8-pin header USB23
Table 4-1: Peripheral Interface Connectors
4.1.3 External Interface Panel Connectors
Table 4-2 lists the rear panel connectors on the NANO-9452. Detailed descriptions of
these connectors can be found in Section 4.3 on page 57
Connector Type Label
Ethernet connector RJ-45 LAN1
Ethernet connector RJ-45 LAN2
Keyboard and mouse connector PS/2 connector KB_MS1
RS-232 serial port connector Male DB-9 COM1
USB port USB port USB_C45
