background image

NANO-9452 EPIC Motherboard

Page 41

FUNCTION PIN DESCRIPTION

FUNCTION

PIN DESCRIPTION

1 PWRBTSW-

2 VCC

Power

Button

3 Ground

Power LED

4 Ground

5 VCC

6 SYSRST-

HDD LED

7 HDD

LED-

Reset

8 GND

Table 4-10: Front Panel Connector Pinouts

4.2.9 IDE Connector(44-pin)

CN Label:

KB1

CN Type:

44-pin header (2x22)

CN Location:

See Figure 4-11

CN Pinouts:

See Table 4-11

One 44-pin IDE device connector on the NANO-9452 supports connectivity to two hard

disk drives.
