NANO-9452 EPIC Motherboard
Page 6
LCD voltage selector
CF card setting
COM 2 port mode setting
PC104+ VIO selector
PC104+ SERIRQ# support
1.2.3 Technical Specifications
NANO-9452 technical specifications are listed in Table 1-1. See Chapter 2 for details.
Specification NANO-9452
Form Factor EPIC
System CPU
Socket 479 Intel® Core™ 2 Duo Mobile
Socket 479 Intel® Core™ Duo
Socket 479 Intel® Core™ Solo
Front Side Bus 667MHz
System Chipset
Northbridge: Intel® 945GME
Southbridge: Intel® ICH7M
Memory
One 200-pin SO-DIMM socket supports one
400/533/667 MHz DDR2 SO-DIMM with a maximum capacity
of 2.0 GB
Display
CRT: Integrated in the Intel® 945GME to support CRT
TV-Out: S-Video and composite output
LVDS: Dual channel 18-bit / 24-bit LVDS LCD panel
BIOS AMI BIOS
Audio 7.1 channel or 5.1 channel audio with an optional AC-KIT
LAN Two Broadcom PCIe GbE controllers
COM
Three RS-232 serial ports (two internal, one external)
One RS-232, RS-422 or RS-485 serial port
USB2.0 Six USB 2.0 devices supported
IDE One 44-pin IDE connects to two Ultra ATA33 devices
