NANO-9452 EPIC Motherboard
Page 75
Description Label Type
CF card setup JCF1 2-pin header
Clear CMOS J_CMOS1 3-pin header
COM 2 function select JP1 5-pin header
LVDS voltage selection J_VLVDS1 3-pin header
PC104+ VIO Selector JP2
PC104+ SERIRQ# support JP3
Table 5-1: Jumpers
5.4.1 CF Card Setup
Jumper Label: JCF1
Jumper Type: 2-pin header
Jumper Settings: See Table 5-2
Jumper Location: See Figure 5-9
The CF Card Setup jumper sets the CF Type I card or CF Type II cards as either the slave
device or the master device. CF Card Setup jumper settings are shown in Table 5-2.
AT Power Select Description
Open Slave Default
Closed Master
Table 5-2: CF Card Setup Jumper Settings
The CF Card Setup jumper location is shown in Figure 5-9.
