IMB-H610 Mic ro -ATX Mo th e rb o a rd
P a g e 45
PIN DESCRIPTION PIN DESCRIPTION
15 GND 16 HPD
17 DATA0- 18 DATA0+
19 GND 20 NC
21 NC 22 GND
23 CLOCK+ 24 CLOCK-
Table 3-30: DVI Connector Pinouts
