3.1.2 P e rip h e ra l In te rfa c e Co n n e c to rs
The table below lists all the connectors on the board.
Co n n e c to r Typ e La b e l
ATX power connector 24-pin ATX ATX
Battery connector Battery holder BAT1
CPU fan connector 4-pin wafer CPU_FAN
CPU power connector 4-pin Molex CPU12V1
DDR3 DIMM slots DDR3 DIMM slot CHA_DIMM1,
CHB_DIMM1
Debug port connector 9-pin header TS1
Digital I/O connector 10-pin header DIO1
Front panel audio connector 10-pin header FP_AUDIO
Front panel connector 14-pin header F_PANEL
I2C connector 4-pin wafer I2C_1
PCIe power connector 4-pin Molex PCIE_POWER
PCIe x16 slot PCIe x16 slot PCIEX16
PCIe x1 slots PCIe x1 slot PCIEX1_SLOT1,
PCIEX1_SLOT2,
PCIEX1_SLOT3,
SATA 3Gb/s drive connectors 14-pin SATA
connector
SATA12, SATA34
Serial port connector, RS-422/485 4-pin wafer COM4
Serial port connectors, RS-232 10-pin box header, COM3, COM5,
COM6
Serial port connectors, RS-232 40-pin box header COM7-10
SMBus connector 4-pin wafer SMBUS_1
SPI connector 8-pin header SPI
