IMB-H610 Mic ro -ATX Mo th e rb o a rd
P a g e 26
Figure 3-10: Front Panel Connector Location
FUNCTION PIN DESCRIPTION FUNCTION PIN DESCRIPTION
PWR_LED
1 ACPILED
BUZZER
2 BEEP_PWR
3 NC 4 NC
5 GND 6 NC
PWR_BTN
7 PWRBTN_SW#_C 8 PC_BEEP
9 GND
RESET
10 NC
HDD_LED
11 IDELED 12 EXTRST-
13 IDELED- 14 GND
Table 3-9: Front Panel Connector Pinouts
3.2.10 I2C Co n n e c to r
CN La b e l: I2C_1
CN Typ e : 4-pin wafer
CN Lo c a tio n : See Figure 3-11
CN P in o u ts : See Table 3-10
The I2C connector is for system debug.
