Warner Electric MTB II - Manual (Page 9)

Armature A B C BORE D E F G
Size Max. Stock* Bushing Max. Max. Max. Degree
10" 8.625 ± .020 9.500 1.750 .500–1.750 10.020 .479 3.550 180
(219.0 ± 0.5) (241.3) (44.45) (14.0–42.0) (254.5) (12.2) (88.9)
13" 10.187 ± .020 11.000 3.375 1.125–3.750 13.520 1.219 5.687 108 &
(258.7 ± 0.5) (279.4) (85.73) (28.0–95.0) (343.4) (31.0) (144.4) 144
15" 11.125 ± .020 12.000 3.375 1.125–3.750 15.325 1.219 6.875 120
(282.6 ± 0.5) (304.8) (85.73) (28.0–95.0) (389.3) (31.0) (174.6)
20" 13.470 ± .020 14.250 — 2.375–5.500 20.020 2.720 4.380 —
(340.4 ± 0.5) (362.0) — — (508.5) (69.1) (111.3)
* Stock bore is straight bore for use with Trantorque bushing.
9 Warner Electric • 800-825-9050 819-0342
Modular Tension Brake–Universal Mounting Brackets
.404
.395 10.26
10.03
3.500 .003
(88.9 .762)
1/2-14 NPT
B
Radius
3.300
(83.8)
2.400
(61.0)
.500
(12.7)
.200
(5.08)
SET-UP
.200
(5.08)
SET-UP
1.644
(41.8)
E E
F
1.500
(38.1)
5.085 (129.2) MAX.
1.835
(46.6)
.500
(12.7) 1/2-14 NPT
(Shown with
Dust Plug)
HOLES
1.750
(44.5)
1.210 (30.7)
.630
(16.0)
MIN.
A
C
BORE
D
DIA.
G
DEG.
( )
1.322
(33.58)
7.125 (181.0) MAX.
inch (metric)
All Dimensions Nominal unless specified
Dual Armature Single Armature
