MODEL CT-7500 OPERATING INSTRUCTIONS
Rev 2 Jan 2001
55
9.17 Set CT-7500 Internal Clock
The CT-7500 has an internal clock with a lithium battery. The clock's time and date is
displayed on the LCD screen. When a timing shot is stored in EEPROM, time and date are also
stored. To set the clock, perform the steps in the following table:
Table 9-18. Setting the Clock and Calendar
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS # 3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT NEXT PAGE. PRESS # 4 KEY. 1. SHOT DESCRIPTION
2. NUMBER OF CHANNELS
3. COMPUTER IF
4. CLOCK 5.PRINT
3 SELECT SET CLOCK. PRESS # 4 KEY. TIME: HH:MM:00
XX:YY:00
4 ENTER HOURS AND MINUTES. PRESS # 0-9 KEY. TIME: HH:MM:00
XX:YY:00 XX:YY:00
DATE: MM/DD/YY
XX/YY/ZZ
5 ENTER MONTH, DATE, YEAR. PRESS # 0-9 KEY. TIME: HH:MM:00
XX:YY:00 XX:YY:00
DATE: MM/DD/YY
XX/YY/ZZ XX/YY/ZZ
6 RETURN TO MAIN MENU. NO ACTION. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
Note
The real time clock battery is good for 3 years. Loosing the clock battery will not affect the CT-
7500 performance.
