MODEL CT-7500 OPERATING INSTRUCTIONS
Rev 2 Jan 2001
53
Table 9-16. Setting Up "OPEN" Analysis Points Using Distance (Con’t)
STEP OPERATION ACTION DISPLAY
8 ENTER 5 INCHES. PRESS # 0-9 KEYS. OPEN ANALYSIS PT 2
DISTANCE FROM CLOSE
VALUE: 02.00 in
"ENTER" TO CONFIRM
9 CONFIRM ENTRY. PRESS "ENTER"
KEY. 1.TIME BRKR
2.GET RSLT
3.SET UP
4.DIAGNOSTICS
NOTES
1. If an entry is not correct, re-enter digits until display shows desired numbers, then press
“ENTER” key.
2. Analysis Point #1 is 1.00 inch from the fully closed position.
3. Analysis Point #2 is 2.00 inches from the fully closed position.
