MODEL CT-7500 OPERATING INSTRUCTIONS
54
Rev 2 Jan 2001
9-16. English/Metric Selection
The CT-7500 supports and displays both English and Metric calculations from the breaker's
travel parameters (stroke, velocity, (etc.). The user can switch from one to the other by following
the steps in Table 9-17, below:
Table 9-17. Select Metric Units of Measure
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS # 3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT MEASUREMENT UNITS. PRESS # 2 KEY. SELECT UNITS
1. ENGLISH
2. METRIC
3 SELECT METRIC. PRESS # 2 KEY. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
