MODEL CT-7500 OPERATING INSTRUCTIONS
46
Rev 2 Jan 2001
9.11 Shot Description
The CT-7500 lets users enter breaker and test data identification (ID). This data includes the
names of the company, station, circuit, and manufacturer, as well as the breaker's model and
serial number, and the operator's name. These ID data will print out on the header section of the
shot tabulated report.
If the user saves the timing shot, this data will also be saved with the timing shot and the time
and date.
The user selects the alpha-numeric entry by pressing the appropriate key: To select a letter "A,"
the user must press key #2 twice. To select letter "C," the user must press key #2 four times etc.
To move the cursor forward, use the UP ARROW key. To move cursor backwards, use the
DOWN ARROW key. Use the CLEAR key to enter a space.
Table 9-13. Entering Shot Identification Header
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS #3 KEY. 1. ANALYSIS POINTS
2. MEASUREMENT UNIT
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT NEXT PAGE. PRESS # 4 KEY. 1. SHOT DESCRIPTION
2. NUMBER OF CHANNELS
3. COMPUTER IF
4. SET CLOCK
3 SELECT SHOT DESCRIPTION. PRESS # 1 KEY. ENTER COMPANY NAME
XXXXXX
"ENTER" TO CONFIRM
4 ENTER COMPANY NAME. PRESS # 0-9 KEYS
PRESS "ENTER"
TO CONFIRM. ENTER STATION NAME
XXXXXX
"ENTER" TO CONFIRM
5 ENTER STATION NAME. PRESS # 0-9 KEYS
PRESS "ENTER"
TO CONFIRM. ENTER CIRCUIT NAME
XXXXXX
"ENTER" TO CONFIRM
6 ENTER CIRCUIT NAME. PRESS # 0-9 KEYS
PRESS "ENTER"
TO CONFIRM. ENTER MANUFACTURER NAME
XXXXXX
"ENTER" TO CONFIRM
7 ENTER MANUFACTURER NAME. PRESS # 0-9 KEYS
PRESS "ENTER"
TO CONFIRM. ENTER BREAKER MODEL
XXXXXX
"ENTER" TO CONFIRM
