MODEL CT-7500 OPERATING INSTRUCTIONS
Rev 2 Jan 2001
27
commands are initiated at the same time. The breaker will start closing, the OPEN circuit is
then enabled (by the A/B switch) allowing the OPEN operation.
9.2 Get Tabulated Timing Results Using Thermal Printer
Table 9-4. Get Tabulated Results
STEP OPERATION ACTION DISPLAY
1 GET TIMING RESULTS. PRESS #1 KEY. 1.PRINT TEST RESULTS
2.PLOT FULL CHART
3.PLOT EXPANSION
4.PLOT 0-200 MS
2 PRINT TABULATED RESULTS. PRESS #1 KEY. SELECT PRINTER
1. INTERNAL THERMAL
2. EXTERNAL INKJET
3 OUTPUT TABULATED RESULTS ON
THERMAL PRINTER. PRESS #1 KEY. 1. PRINT TEST RESULTS
2. PLOT FULL CHART
3. PLOT EXPANSION
4. PLOT 0-200 MS
Note
To get a tabulated report on the ink-jet printer, press key #2 in step #2. Ensure the ink-jet printer
is connected to the CT-7500 for this report.
