MODEL CT-7500 OPERATING INSTRUCTIONS
Rev 2 Jan 2001
43
9.9 Print a Breaker Test Plan
The user can print a breaker test plan stored in the CT-7500 EEPROM
Table 9-11. Print a Breaker Test Plan
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS # 3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT ANALYSIS POINTS. PRESS # 1 KEY. 1. OPEN TIMING
2. CLOSE TIMING
3. PRINT SETTINGS
4. TEST PLAN
3 SELECT TEST PLAN. PRESS # 4 KEY. 1. LOAD TEST PLAN
2. PRINT TEST PLAN
3. PRINT DIRECTORY
4 SELECT PRINT TEST PLAN. PRESS # 2 KEY. ENTER PLAN NUMBER
"ENTER" TO CONTINUE
5 ENTER PLAN NUMBER. PRESS # 0-9 KEY. ENTER PLAN NUMBER:
02
"ENTER" TO CONTINUE
6 CONFIRM TEST PLAN. PRESS “ENTER" KEY. SELECT PRINTER
1. INTERNAL THERMAL
2. EXTERNAL INK JET
7 PRINT ON THERMAL PRINTER. PRESS # 1 KEY. 1. TIMER BRKR
2. GET RESLT
3. SET UP
4. DIAGNOSTIC
