MODEL CT-7500 OPERATING INSTRUCTIONS
38
Rev 2 Jan 2001
9.5 Print EEPROM Timing Shot Directory
Table 9-7. Print Timing Shot Directory
STEP OPERATION ACTION DISPLAY
1
SELECT SAVE / RESTORE MENU.
PRESS #3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT SHOT DIRECTORY MENU. PRESS #3 KEY. 1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
3 SELECT SHORT DIRECTORY. PRESS # 1 KEY. 1. SHORT DIRECTORY
2. FULL DIRECTORY
"STOP" TO QUIT
4 PRINT SHOT DIRECTORY NOW. NO ACTION. PRINTING ABBREVIATED
DIRECTORY
"STOP" TO QUIT
5 RETURN TO MAIN DIRECTORY. NO ACTION. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
Note
1. The CT-7500 will print out shot IDs of 10 last timing shots stored in EEPROM when "Short
Directory" is selected.
2. The CT-7500 will print out shot IDs of all timing shots stored in EEPROM if "Full Directory" is
selected.
A typical shot directory print out is shown on next page.
