MODEL CT-7500 OPERATING INSTRUCTIONS
42
Rev 2 Jan 2001
9.8 Recall a Breaker Test Plan
A breaker test plan contains breaker maximum/minimum operating parameters. A typical list of
operating parameters is shown as follows:
„ Max/Min Contact/Resistor Trip Time.
„ Max/Min Contact/Resistor Close Time.
„ Max Contact Spread Time.
„ Max Resistor Contact Spread Time.
„ Max/Min Stroke.
„ Max/Min Trip Velocity.
„ Max/Min Close Velocity.
„ Max/Min Over Travel.
„ Max/Min Bounce Back.
„ Trip Analysis Points.
„ Close Analysis Points.
By recalling a Test Plan before testing, a user doesn't have to set analysis points to calculate
the Trip or Close velocity of the circuit-breaker contacts. Since a Test Plan contains other breaker
test parameters, the test report also displays a Pass/Fail status for each parameter tested.
Table 9-10. Recalling a Test Plan
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS #3 KEY. 1. ANALYSIS POINTS
2. MEASUREMENT UNIT
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT ANALYSIS MENU. PRES # 1 KEY. 1. OPEN TIMING
2. CLOSE TIMING
3. PRINT SETTING
4. TEST PLANS
3 SELECT TEST PLANS. PRESS # 4 KEY. 1. LOAD TEST PLAN
2. PRINT TEST PLAN
3. PRINT DIRECTORY
4 SELECT LOAD TEST PLAN. PRESS # 1 KEY. LOAD TEST PLAN
"UP" TO SCROLL
"ENTER" TO SELECT
5 VIEW TEST PLAN HEADER. PRESS UP ARROW
KEY TO SCROLL. DISPLAY TEST PLAN HEADER
6 CONFIRM TEST PLAN TO BE
LOADED. PRESS "ENTER"
KEY. 1. TEST BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
