9.15 Set-Up Open Analysis Points
Table 9-16. Setting Up "OPEN" Analysis Points Using Distance
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS # 3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT ANALYSIS POINT. PRESS # 1 KEY. 1. OPEN TIMING
2. CLOSE TIMING
3. PRINT SETTING
4. TEST PLAN
3 SELECT OPEN ANALYSIS. PRESS # 1 KEY. OPEN ANALYSIS PT 1
1. PERCENT OF STROKE
2. DISTANCE FROM CLOSE
3. CONTACT #1
4 SELECT DISTANCE FROM CLOSE. PRESS # 2 KEY. OPEN ANALYSIS PT 1
DISTANCE FROM CLOSE
VALUE: XX.XX in
"ENTER" TO CONFIRM
5 ENTER 1 INCH. PRESS # 0-9 KEY. OPEN ANALYSIS PT 1
DISTANCE FROM CLOSE
VALUE: 01.00 in
"ENTER" TO CONFIRM
6 CONFIRM ENTRY. PRESS "ENTER" KEY. OPEN ANALYSIS PT 2
1. PERCENTAGE OF STROKE
2. DISTANCE FROM CLOSE
7 SELECT DISTANCE FROM CLOSE. PRESS # 2 KEY. OPEN ANALYSIS PT 2
DISTANCE FROM CLOSE
VALUE: XX.XX in
"ENTER" TO CONFIRM
