MODEL CT-7500 OPERATING INSTRUCTIONS
40
Rev 2 Jan 2001
9.6 Recall a Timing Shot
The following steps are used to recall a timing shot stored in EEPROM to working memory.
Once a timing shot is recalled, the user can ask for test results from the thermal printer or the
color ink-jet printer.
Table 9-8. Recall a Timing Shot
STEP OPERATION ACTION DISPLAY
1 SELECT SETUP MENU. PRESS #3 KEY. 1. ANALYSIS POINT
2. MEASUREMENT UNITS
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT SAVE/RESTORE SHOT. PRESS # 3 KEY. 1. SAVE SHOT
2. RESTORE SHOT
3. SHOT DIRECTORY
4. ERASE SHOT
3 SELECT RESTORE SHOT. PRESS #2 KEY. ENTER SHOT NUMBER TO BE RESTORED
xxxx
"ENTER" TO CONFIRM
4 ENTER SHOT NUMBER TO BE
RESTORED. PRESS KEY 0 TO 9
FOR SHOT ID THE
"ENTER" KEY. ENTER SHOT NUMBER TO BE RESTORED
XXXX
"ENTER" TO CONFIRM
5 CONFIRM SHOT TO BE RESTORED. PRESS "ENTER"
KEY. RESTORING SHOT # XXXX
TEST: YYYY
DATE: MM\DD\YY HH:MM
"ENTER" TO CONFIRM
6 RETURN TO MAIN MENU. PRESS ANY KEY. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTICS
