MODEL CT-7500 OPERATING INSTRUCTIONS
Rev 2 Jan 2001
31
9.3 Get Graphic Timing Results Using Thermal Printer
Table 9-5. Plot Chart and Tabulated Report
STEP OPERATION ACTION DISPLAY
1 GET TIMING RESULTS. PRESS #2 KEY. 1 PRINT TEST RESULTS
2 PLOT FULL CHART
3 PLOT EXPANSION
4 PLOT 0-200 MS
2 PLOT FULL CHART. PRESS #2 KEY. SELECT PRINTER
1. INTERNAL THERMAL
2. EXTERNAL INKJET
3 PRINT CHART ON THERMAL PAPER. PRESS #1 KEY. PLEASE WAIT
PLOTTING GRAPH
4 RETURN TO MAIN MENU AFTER
PRINT CHART. NO ACTION. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
Note
1. Figure 9-4 shows a timing chart of a circuit breaker with contact activity on channel 1 and 3. A
CT channel is also shown on this chart. Since this print out was generated to show both Quick-
Shot mode and Time-Travel mode; both CT time and contact-travel readings are shown on this
chart.
2. To get a graphic report on the ink-jet color printer, press key #2 in step # 2.
