9.12 CT-7500 Channel Configuration
The CT-7500 is available with 3-, 6-, or 12- contact inputs. Under most common timing
conditions, the user needs to use only 3 contact timing channels and 1 travel transducer. There is
no need to print more than 3 timing channels and 1 transducer channel on the graphic and
tabulated report. The CT-7500 will always default to 3 contact channels (channel 1, 2, and 3) and
1 transducer channel (transducer channel #1) after power is applied to the unit. The user can
always turn on the rest of the timing channels and transducer channels by following steps shown
in table below:
Table 9-14. Select Channel Configuration
STEP OPERATION ACTION DISPLAY
1 SELECT SET UP MENU. PRESS #3 KEY. 1. ANALYSIS POINTS
2. MEASUREMENT UNIT
3. SAVE / RESTORE
4. NEXT PAGE
2 SELECT NEXT PAGE. PRESS #4 KEY. 1. SHOT DESCRIPTION
2. NUMBER OF CHANNELS
3. COMPUTER IF
4. SET CLOCK
3 SELECT NUMBER OF CHANNEL. PRESS #2 KEY. NUMBER OF CHANNELS
1. 3 CONTACTS
2. 6 CONTACTS
3. 12 CONTACTS
4
SELECT 3 CHANNELS ,OR 6
CHANNELS, OR 12 CHANNELS.
PRESS # 1, OR 2, OR
3 KEY. 1. TRANSDUCER 1
2. TRANSDUCER 1,2
3. TRANSDUCER 1,2,3
5 SELECT 1 TRANSDUCER, OR 2, OR 3. PRESS # 1, OR 2, OR
3 KEY. 1. TIME BRKR
2. GET RSLT
3. SET UP
4. DIAGNOSTIC
