ADDITIONAL APPLICATIONS

HYDRAULIC SYSTEMS: Partially blocked or bypassed valves in

high-pressure hydraulic systems can be difficult and costly to find

with conventional methods. Since hydraulic systems employ very

high pressures, the intensity of the ultrasonic sound given off by

an internal leak is extremely high and easily detected by the

receiver.

Use the hollow air probe, solid contact probe or use

the receiver alone.

WATER LEAKS IN ROOFS, WINDOWS OR DOORS:

Place the

activated emitter below the suspected leak area. Check the

suspected part of the roof, window or door with the receiver to

isolate where the leak originates. This will also aid in the detection

of any leaks in the area.

Use the hollow air probe or use the

receiver alone. (See figures below.)

Emitter

Receiver
