MP Tests
General Component Protocol checklist (master)
Below are the list of requested transactions and their corresponding tests.
Please note that the addresses shown in the examples are based on the test setup, your system
may result different addresses. Be sure to do test 1.09 to see what the addresses are free for
each Memory, I/O and Configuration spaces.
Some of MP tests are interrelated, These tests are:
1. MP_06 - MP_07 - MP_14 - MP_15 - MP_16
2. MP_24 - MP_25
3. MP_28 - MP_29
The required transactions for each set of tests are the same, thus once one of these tests is executed
and the required transaction is performed there will be no message for the next test(s) to perform a
transaction. For example to execute test MP_14 only, a message will ask for executing a memory
read command with three data phases. But if tests MP_06 or MP_07 have been executed prior to
MP_14 the software will not require the memory read transaction again when MP_14 is to be
executed.
There is no priority for which test to be executed first. For example MP_25 may be executed first
and then MP_24,and the software will only requests the transaction to be performed for the first test.
It should be noted that the title of the message box is always includes the name of the first test in the
group, so even only MP_25 is executed the title will be “Compliance Test MP_24”.
