Teledyne LeCroy PETrainer Scripting Language
76
Structure=NVMe
{
Location=Mem64
Offset = 0x1000
NVMeStructType = NVMCommand
OpcodeNvm = Write
CID = 5
NamespaceId = 1
PRP1_Low = 0xA0000000
PRP1_High = 0x4
StartLBALow = 12
NumLBlocks = 0
}
Structure=NVMe
{
Location=Mem64
Offset = 0x1040
NVMeStructType = PRP
PageBaseAddrLow = 0xCD000000
PageBaseAddrHigh = 0xA0B
}
Examples of AHCI structures:
Structure=AHCI
{
Location=Mem64
Offset = 0
AhciStructType=Command
PRDTL = 1
FISLength = 5
CTBA = 0xA0001000
CTBAU = 0x4
}
Structure=AHCI
{
Location=Mem64
Offset = 0x1000
AhciStructType=FIS
FISType = RegisterH2D
ATACommand = IDENTIFY_DEVICE
C = Yes
Device = 0xA0
}
Structure=AHCI
{
