Page 40: Config = general
Teledyne LeCroy
PETrainer Scripting Language
35
6 Config Command
This command configures the PETrainer™.
6.1 Config = General
This command should precede any statement in a PETrainer script file. There should be only one
Config = General command in a PETrainer script file. All Config = General commands from included
files (see page 70) are ignored.
Parameter
Values
Default Comment
AutoDetect
Yes, No
No
Automatically detect link parameters.
LinkWidth
1,4,8,16
4
Ignored in PETrainer ML if AutoDetect
is set.
DirectionRx
Upstream, Downstream
U
DisableScrambleTx
Yes, No
No
Ignored if AutoDetect is set.
DisableDescrambleRx
Yes, No
No
Ignored if AutoDetect is set.
ReverseLanesTx
Yes, No
No
Ignored if AutoDetect is set.
ReverseLanesRx
Yes, No
No
Ignored if AutoDetect is set.
InvertPolarityTx
(X,X,X,X,…)
The array of 1/0 elements.
The size of the array should match the
link width.
InvertPolarityRx
(X,X,X,X,…)
The array of 1/0 elements.
The size of the array should match the
link width.
Ignored if AutoDetect is set.
BaseSpec10
Yes, No
No
SkewTx
(X,X,X,X,…)
The array of integer elements.
The size of the array should match the
link width.
Measured in symbols, valid values are
from 0 to 7.
UseExtRefClock
Yes, No
No
Use external reference clock.
Applicable for PETrainer ML only.
TrainerReset
Yes, No
No
When set, resets PETrainer before
script execution.
