Teledyne LeCroy PETrainer Scripting Language
7
Example 2:
Read 32 DWORDs of data starting from address 0x1000.
PSN would accept values 0 for first TLP and 1 for second TLP.
TC, EP, Ordering, and Snoop parameters are not specified, so the default value of 0 is used.
LCRC is not specified, so the LCRC is calculated by software.
ECRC is not specified, so the ECRC is calculated by software.
Packet = TLP {
PSN = Incr
TLPType = MRd32
Tag = 0
Address = 0x1000
TD = 1
FirstDwBe = 0xF
Length = 16
}
Packet = TLP {
PSN = Incr
TLPType = MRd32
Tag = 1
Address = 0x1010
TD = 1
FirstDwBe = 0xF
Length = 16
}
Example 3:
This example does not specify PSN, Tag, and LCRC. Those values are calculated automatically by the
PETrainer hardware (see more on Config = TLP command, Page 39).
Config = TLP {
AutoSeqNumber = Yes
AutoLCRC = Yes
TagGeneration = Default
}
Packet = TLP {
TLPType = MRd32
Address = 0x1010
TD = 1
Length = 1
}
Example 4:
This example shows how to specify a reserved field in the TLP header using the RawData parameter
(see more on the RawData parameter, Page 29).
Packet = TLP {
TLPType = MRd32
Address = 0x1010
RawData@4 = ( D1 )
}
